M+E Meredith and Eyre MEG 7564 TRM inc Mesh Sides & Ramp Tailgate


M+E Meredith and Eyre MEG 7564 + Mesh Sides

SKU: M&E02 Category:


MEG 7564 TRM  Un-Braked Goods Trailer

This range of Un-braked Trailers have a strong A-frame drawbar arrangement, with a quality 50mm Ball Coupling and prop stand as standard.

The durability of heavy duty, low maintenance rubber torsion axle has been proven in the Construction Plant industry and it has soft ride characteristics ideal for when the trailer is empty.

The Floor of the trailer is made from 18mm slip resistant high-density plywood with a tough, waterproof resin coating on both sides.


  • Max Gross Weight: 750Kg
  • Payload:                      575Kg with Tailgate – 560kg with Ramp
  • Loading Height:      405mm
  • Height of Sides:       305mm
  • Mesh sides                 630mm
  • Total Side height     935mm
  • Width: External:      1745mm
  • Width (Internal):     1220mm (4’)
  • Length: External:     3000mm
  • Length (Internal):    1985 mm (6’6”)
  • Tyre Size:                    20.5 x 10
  • Hot Dip Galvanised Body
  • High Quality Rubber Suspension Axles
  • Includes Spare Wheel & Tyre
  • 18mm Phenolic Coated Floor
  • Includes 1000mm Integral Ramp Tailgate
  • Includes mesh sides
